Optical System Design

Preliminary design stage

According to the overall technical requirements of the optical instrument, such as performance indicators, shape, etc., from the overall point of view of the optical instrument, the schematic diagram of the optical system is formulated, and the external dimensions of the optical system are preliminarily calculated, the structure type is determined, and the optical focal length between the light groups is assigned.

Aberration design stage

According to the preliminary design results, determine the specific structural parameters of each lens group, such as radius of curvature, thickness, spacing and material, etc., to meet the requirements of the optical characteristics and imaging quality of the system.

Optical Design
